AMP-D225H Class D Amplifier, 2-Channel, 400Hz to 500kHz Frequency
Please sign in so that we can notify you about a reply
The AMP-D225H is a two-channel class D amplifier delivering 25 watts per channel in a sleek, compact design. Because there is no need for internal cooling fans, the AMP-D225H can be placed in a conference room with virtually no audible noise. The ability to bridge channels gives even more power and flexibility to the AMP-D225H. The AMP-D225H is also equipped with four stereo inputs, four GPIO, and two RS-232 interfaces. It integrates easily with a variety of control systems and the USB input enables direct audio connection and volume control from a computer. It’s audio performance, ease-of-use, and versatile feature set makes the AMP-D225H ideal for a variety of professional audio applications
Features- Two channels; 25W per channel
- Bridgeable channels
- Class D amplifier topology
- Supports 4Ω and 8Ω outputs
- 4 GPIO for control of relays, switches, and sensors
- 3 band equalizer for bass, mid and treble control
- Auto standby mode
- Covered by Biamp Systems’ five-year warranty
Brand:
Biamp
Specifications
Product Type:
2-Channel Class D Amplifier
Special Features:
Bridgeable Channels, Class D Amplifier Topology
Maximum Operating Temperature:
+30°C
Indicator Type:
LED
Humidity:
10 to 90% (Non-Condensing)
Minimum Operating Temperature:
0°C
Includes:
2 RS-232 Connection
Performance
Frequency Rating:
400Hz to 500kHz
Input Impedance Rating:
<100kΩ
Inputs and Ports
Connector Type:
RCA
Input Type:
4xStereo Line Level Audio Input, 1xUSB Audio Input
Power
Input Voltage:
24V DC
Standards
Standards Met:
CE, UL Listed, and RoHS Compliant
Dimensions
Width:
21.8cm
Depth:
44.4cm
Height:
3.7cm
Weight:
10.1kg
