PM4100 Multi-Functional Stereo Preamplifier, 400Hz to 500kHz Frequency
Please sign in so that we can notify you about a reply
The PM4100 is a multi-functional stereo preamplifier controlled via the network or RS-232 connection. The PM4100 is equipped with four stereo inputs, 4 GPIO, and one stereo output. It integrates easily with a variety of control systems and the USB input enables direct audio connection and volume control from a computer. The PM4100 can be powered by either PoE or 12V DC. It’s audio performance, ease-of-use, and versatile feature set makes the PM4100 ideal for a variety of professional audio applications
Features- Four unbalanced stereo inputs
- One balanced stereo output
- 2 bi-directional RS-232 ports for third party control with feedback
- 4 GPIO for control of relays, switches, and sensors
- Possible to mix Input 1 with the current selected input
- 3 band equalizer for bass, mid and treble control
- Auto standby mode
- PoE powered (IEEE 802.3at Class 2, 7W)
- When powered by PoE the 12V DC output supplies power for external devices such as control systems
- Covered by Biamp Systems’ five-year warranty
Brand:
Biamp
Specifications
Product Type:
Multi-Functional Stereo Preamplifier
Special Features:
Four Unbalanced Stereo Inputs
Maximum Operating Temperature:
+30°C
Humidity:
10 to 90% (Non-Condensing)
Minimum Operating Temperature:
0°C
Includes:
2 RS-232 Connection
Performance
Frequency Rating:
400Hz to 500kHz
Input Impedance Rating:
<100kΩ
Inputs and Ports
Connector Type:
5-Pin, 0.3 in Euroblock
Power
Input Voltage:
12V DC
Output Impedance Rating:
100Ω
Standards
Standards Met:
CE, UL Listed, and RoHS Compliant
Dimensions
Width:
21.8cm
Depth:
44.1cm
Height:
3.7cm
Weight:
9.3kg
