OPS-108S Rack mountable Optical Splitter, 1xFibre Input, 8xFibre Outputs, 1260 to 1650 nm
Please sign in so that we can notify you about a reply
Features
- Distributes optical signal over single-mode fiber up to sixteen (16) channels without any active device or electrical power
- Each unit can be used as stand-alone
- Compatible products: DVFX-110-TR, M1-201DA-TR, M1-203D-TR, SDIX-100, SDISE-100, and M1-3R2VI-DU
- Dimensions (WDH): 432 x 150 x 43.8mm (OPSR-2) / 189.5 x 191 x 39mm (OPS-xyz)
Brand:
Opticis
Specifications
Product Type:
Optical Splitter
Splitter Type:
1x8
Optical Connection Type:
SC
Splitter Number:
2
Special Features:
Distributes Optical Signal Over Single-Mode Fibre Up to Sixteen (16) Channels Without any Active Device or Electrical Power
Performance
Operating Wavelength:
1260 to 1650nm
Return Loss:
≥ 55dB
Insertion Loss:
≤11 (Maximum), ≤1 ( Uniformity)
Inputs and Ports
I/O Interface Type:
1xFibre Input, 8xFibre Output
Dimensions
Width:
18.95cm
Depth:
19.1cm
Height:
3.9cm
