TesiraFORTÉ AVB CI AVB CI Fixed I/O DSP, 12 Mic/Level (Input)/8 Mic/Level (Output), 4-Pin GPIO/RS232/Ethernet/RJ45
Please sign in so that we can notify you about a reply
The TesiraFORTÉ AVB CI is a digital audio server with 12 analog inputs — each with Acoustic Echo Cancellation (AEC) technology, 8 analog outputs, and up to 8 channels of configurable USB audio. TesiraFORTÉ AVB CI utilizes AVB/TSN digital audio networking, and can be used as a standalone device or combined with other TesiraFORTÉ AVB devices and Tesira servers, expanders, endpoints, and controllers.
The TesiraFORTÉ AVB CI complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.
Features
- 128 x 128 channels of AVB
- 12 mic/line level inputs with AEC, 8 mic/line level outputs
- Gigabit Ethernet port
- RS-232 serial port
- 4-pin GPIO
- 2-line OLED display with capacitive-touch navigation
- Rack mountable (1RU)
- System configuration and control via Ethernet
- Internal universal power supply
- Signal processing via intuitive software allows configuration and control for signal routing, mixing, equalization, filtering, and delay
- CE marked, UL listed, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
- Compliant with the US Trade Agreement Act (TAA)
Brand:
Biamp
Specifications
Product Type:
AVB CI Fixed i/o Dsp
Mounting Type:
Rack Mount
Number of Channels:
USB Sample Rate:
48kHz
Power Rating:
<35W
Maximum Operating Temperature:
40°C
Applications:
Conference Room, Learning Environment
Minimum Operating Temperature:
0°C
Performance
Impedance Rating:
8kΩ
Dynamic Range:
22Hz to 22KHz
Frequency Rating:
20Hz to 20KHz
Sample Rate:
48kHz
A/D Conversion:
24bits
USB Bit Depth:
16/24bits
Inputs and Ports
Connector Type:
4-Pin GPIO, RS-232, Ethernet, RJ45
Number of Ports:
12 Mic/Level (Input), 8 Mic/Level (Output)
Connectivity
Networking Port:
Gigabit Ethernet
Power
Voltage Rating:
100 TO 240V AC
Current Rating:
7mA
Phantom Voltage Rating:
+48V DC
Standards
Standards Met:
FCC Part 15B, CE Marked, UL and C-UL Listed, RCM, RoHS Directive
Dimensions
Width:
48.3cm
Depth:
26.7cm
Height:
4.4cm
Weight:
3.6kg
