TesiraFORTÉ AVB VT AVB VT Fixed I/O DSP, 12 Mic/Level (Input)/8 Mic/Level (Output), 4-Pin GPIO/RS232/Ethernet
Please sign in so that we can notify you about a reply
TesiraFORTÉ® DAN VT4 is a fixed I/O DSP with 32 bi-directional channels of Dante™ digital audio, 4 analog inputs, 4 channels of Acoustic Echo Cancellation (AEC) technology, and 4 analog outputs. It also includes up to 8 channels of configurable USB audio, a 2-channel VoIP interface and a standard FXO telephone interface. USB audio allows TesiraFORTÉ to interface directly with USB audio hosts, as well as to take full advantage of today’s most sophisticated conferencing solutions. TesiraFORTÉ DAN VT4 also provides extensive audio processing, including but not limited to: AEC technology, signal routing and mixing, equalization, filtering, dynamics, and delay, as well as control, monitoring, and diagnostic tools;all configured through the Tesira configuration software. TesiraFORTÉ DAN VT4 is best-suited for smaller rooms that require high-quality audio solutions using VoIP, voice lift, mix-minus, and AEC, such as conference rooms or distance learning environments.
Features- 32 x 32 channels of digital audio networking via the Dante protocol
- AES67-enabled Dante endpoint
- 4 mic/line level inputs with AEC, 4 mic/line level outputs
- Gigabit Ethernet port
- Up to 8 channels of configurable USB audio
- RS-232 serial port
- 4-pin GPIO
- Rack mountable (1RU)
- Internal universal power supply
- SIP VoIP interface via a RJ45 connector
- Standard FXO telephone interface via RJ-11 connector
- Signal processing via intuitive software allows configuration and control for signal routing, mixing, equalization, filtering, delay and much more
- CE marked, UL listed, and RoHS compliant
- Covered by Biamp Systems’ 5-year warranty
Brand:
Biamp
Specifications
Product Type:
AVB VT Fixed i/o Dsp
Mounting Type:
Rack Mount
Number of Channels:
USB Sample Rate:
48kHz
Maximum Operating Temperature:
40°C
Applications:
Conference Room, Learning Environment
Minimum Operating Temperature:
0°C
Performance
Impedance Rating:
8kΩ
Dynamic Range:
22Hz to 22KHz
Frequency Rating:
20Hz to 20KHz
Sample Rate:
48kHz
A/D Conversion:
24bits
USB Bit Depth:
16/24bits
Inputs and Ports
Connector Type:
4-Pin GPIO, RS-232, Ethernet
Number of Ports:
12 Mic/Level (Input), 8 Mic/Level (Output)
Connectivity
Networking Port:
Gigabit Ethernet
Power
Current Rating:
7mA
Phantom Voltage Rating:
+48V DC
Standards
Standards Met:
FCC Part 15B, FCC Part 68, Industry Canada CS-03, CE Marked, UL and C-UL Listed, RCM, RoHS Directive
Dimensions
Width:
48.3cm
Depth:
26.7cm
Height:
4.4cm
Weight:
3.6kg
