TesiraFORTÉ DAN VT4 DAN VT4 Fixed I/O DSP, 4 Mic/Level (Input)/4 Mic/Level (Output), 4-Pin GPIO/RS232/Ethernet/RJ45
Please sign in so that we can notify you about a reply
The TesiraFORTE® DAN VT4 is a fixed audio DSP with 32 bi-directional channels of Dante™ digital audio, 4 analog inputs, 4 channels of Acoustic Echo Cancellation (AEC) technology, and 4 analog outputs. It also includes up to 8 channels of configurable USB audio, a 2-channel VoIP interface and a standard FXO telephone interface. USB audio allows TesiraFORTE to interface directly with USB audio hosts, as well as to take full advantage of today's most sophisticated conferencing solutions.
TesiraFORTE DAN VT4 also provides extensive audio processing, including but not limited to - AEC technology, signal routing and mixing, equalization, filtering, dynamics, and delay, as well as control, monitoring, and diagnostic tools, all configured through the Tesira configuration software. TesiraFORTE DAN VT4 is best-suited for smaller rooms that require high-quality audio solutions using VoIP, voice lift, mix-minus, and AEC, such as conference rooms or distance learning environments.
- 32x32 channels of digital audio networking via the Dante protocol
- 4 mic/line level inputs with AEC, 4 mic/line level outputs
- Gigabit Ethernet port
- Up to 8 channels of configurable USB audio
- RS-232 serial port
- 4-pin GPIO
- 2-line OLED display with capacitive-touch navigation
- Rack mountable (1RU)
- System configuration and control via Ethernet
- Internal universal power supply
- SIP VoIP interface via a RJ-45 connector
- Standard FXO telephone interface via RJ-11 connector
- Signal processing via intuitive software allows configuration and control for signal routing, mixing, equalization, filtering, delay and much more
Benefits
- Integrates VoIP, POTS, and USB audio in one product allowing integrators to choose the type of audio conferencing that works best for their installation
- Includes default configuration file allowing for plug-and-play usage
- Highly scalable and cost-effective solution that can grow over time with the needs of the customer
- SpeechSense™ technology to enhance speech processing
- Integrates directly with soft codecs and other USB audio hosts
Brand:
Biamp
Specifications
Product Type:
DAN VT4 Fixed i/o Dsp
Mounting Type:
Rack Mount
Number of Channels:
USB Sample Rate:
48kHz
Power Rating:
<35W
Maximum Operating Temperature:
40°C
Applications:
Conference Room, Learning Environment
Minimum Operating Temperature:
0°C
Performance
Impedance Rating:
8kΩ
Dynamic Range:
22Hz to 22KHz
Frequency Rating:
20Hz to 20KHz
Sample Rate:
48kHz
A/D Conversion:
24bits
USB Bit Depth:
16/24bits
Inputs and Ports
Connector Type:
4-Pin GPIO, RS-232, Ethernet, RJ45
Number of Ports:
4 Mic/Level (Input), 4 Mic/Level (Output)
Connectivity
Networking Port:
Gigabit Ethernet
Power
Voltage Rating:
100 TO 240V AC
Current Rating:
7mA
Phantom Voltage Rating:
+48V DC
Standards
Standards Met:
FCC Part 15B, FCC Part 68, Industry Canada CS-03, CE Marked, UL and C-UL Listed, RCM, RoHS Directive
Dimensions
Width:
48.3cm
Depth:
26.7cm
Height:
4.4cm
Weight:
3.6kg
No reviews found
