VS-411X 4x1 4K HDR HDMI Auto Switcher
Please sign in so that we can notify you about a reply
VS−411X is a high−performance 4x1 automatic switcher for 4K HDR, HDMI video signals. Offering priority and last−connected switching options, it automatically switches according to the selected switching scheme based on active video signal detection.
Features
- Plug & Play Auto Switcher — Automatically plays the switched source signal on the connected display according to user–configured preferences, such as priority or last–connected input. When the user manually switches, by pressing a button, the auto switching is overridden.
- HDMI Signal Switching — HDCP 2.2 compliant, Supporting deep color, x.v.Color™, CEC, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
- Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
- I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures plug & play operation for HDMI source and display systems.
- Audio De–embedding — The digital audio signal passing–through to the HDMI output, is de–embedded, converted to an analog signal and sent to the stereo unbalanced analog audio output. This enables playing the audio on locally connected speakers, in parallel to playing it on the speakers connected to the AV acceptor device (such as TVs with speakers).
- Simple Switching Operation — Local buttons or remotely connected contact–closure buttons for flexible user input selection and switching control.
- Cost–Effective Maintenance — Status LED indicators for HDMI ports facilitate easy local maintenance and troubleshooting. Local firmware upgrade ensures lasting, field–proven deployment.
- Easy Installation — Compact DemiTOOLS® fan–less enclosure for user–reachable table mounting, or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.
Brand:
Kramer
Part number:
20-80548090
Specifications
Product Type:
HDMI Intelligent Auto Switcher
Special Features:
Simple and Powerful Maestro Room Control, Easy Remote Device Control, Plug & Play Auto Switcher, Simple Manual Switching Operation, HDMI Signal Switching, I-EDIDPro™ kramer Intelligent EDID Processing™, Multi-channel Audio Switching, Audio De-embeddin
Maximum Operating Temperature:
+40°C
Colour:
Black
Applications:
Intelligent, High-Quality Auto Switcher for any Corporate or Educational AV Meeting Solution, Smart Controllable Switching in Small to Medium Size Meeting and Training Room
Material:
Aluminium
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Performance
Maximum Resolution:
4K@60Hz (4:4:4)
Inputs and Ports
Video Input Type:
HDMI Connector
Power
Voltage Rating:
5V DC
Voltage Rating:
5V DC
Current Rating:
4A
Standards
Standards Met:
Health, Safety, Environmental, RoHS Compliant, WEEE, CE
Dimensions
Width:
19.05cm
Depth:
5.9cm
Height:
2.7cm
Weight:
0.3kg
