CH-352TX Dual HDMI to IP Transmitter with USB KVM Extension
Please sign in so that we can notify you about a reply
The Dual over IP solution is designed to control and switch between KVM, PCs/ laptops and monitors to any connected devices to controlled dual monitor cross-transmit with single pair of KVM|•Ideal solution for monitoring or displaying multiple sources simultaneously for use in control rooms, conference rooms, classrooms or gaming usage|•This KVM Extender allows you to control your PC using a keyboard, mouse and monitor with a maximum resolution of Full HD 1080p or 1920x1200 at distances of up to 100m using one Cat.6 cables|•Effortless MULTI-computer workflow. Move your mouse, keyboard cursor across to 2 computers and Display|•It supports HDMI 1080p@60, audio and HDCP. Analogue stereo audio, IR and RS-232 signals are also supported.
Features
- Supports basic USB keyboard & mouse functions, not compatible with USB 2.0 devices with high power demands, storage or hubs. USB touch screens or other advanced interface devices/HIDs are not supported
- Simultaneous transmission of video, audio, data over a single Cat.5e/6/7 cable up to 100m (328ft)
- Supports USB keyboard, mouse and storage extension
- Supports IR and RS-232 bypass
- Advanced EDID Supports Internal, External, User mode
- Cross-transmit by move your mouse cursor across up to 2 computers and even copy/paste text, images and fi les from one computer to another
- Effortless Multi-computer workflow
Brand:
Cypress Technology
Specifications
Product Type:
Dual HDMI to IP Transmitter
Encryption:
12bits
Transmission Range:
100m
Number of Channels:
Sound Field:
Stereo
Special Features:
USB Keyboard, Mouse and Storage Extension, IR and RS-232 Bypass, Advanced Edid Supports Internal, External, User Mode, Effortless Multi-Computer Work Flow
Power Rating:
10.8W
Maximum Operating Temperature:
+40°C
Chassis Color:
Black
Chassis Material:
Metal
Applications:
HDMI/USB/Audio/IR/and RS-232 Extension, Broadcasting Dual Sources Over a Standard Ethernet Connection, Touch Panel Point-of-Sale or Advertising Kiosk Extension, Long Distance Data and Video Transmission via Cascading, Remote KVM Control of a System
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
8 Channel LPCM and Standard Bitstream
Performance
Video Format:
1920x1080pixels@60Hz 12bits, 1920x1080pixels@60Hz 12bits
Impedance Rating:
10kΩ
Frequency Rating:
30kHz to 50kHz
Inputs and Ports
Input Port Type:
2xHDMI-Type A, 1x3.5mm Analog Stereo
Output Port Type:
1xGbE LAN (RJ45), 1xAnalog Stereo (3.5mm)
Interface Type:
WebGUI
Power
Voltage Rating:
5V
Voltage Rating:
5V
Current Rating:
2.6A
Standards
Standards Met:
US/EU Standards, CE, FCC Compliant, UL Listed
Dimensions
Width:
23.15cm
Depth:
12cm
Height:
2.5cm
Weight:
636g
