VEX-E2502T UHD+ USB-C over HDBaseT Transmitter with USB KVM
Please sign in so that we can notify you about a reply
This 4K UHD+ HDMI over HDBaseT transmitter and receiver pair uses HDBaseT 3.0, the newest generation of HDBaseT technology, and is the perfect solution for extending full bandwidth (18Gbps) HDMI 2.0, 4K@60Hz (4:4:4, 8-bit) video with HD audio via a single run of Cat.6A/7 cable over distances of up to 40 meters. Multiple control and data signals may also be transmitted along with the audio and video, including bi-directional IR, RS-232, USB 3.0, and Gigabit Ethernet. This Transmitter is ideal for use in any video extension scenario, but they excel when latency-free, uncompressed, high resolution video is critical, such as medical installations, live conferences, and education.
Features
- HDMI 2.0 and DVI 1.0 compatible, HDCP 2.2 and HDCP 1.x compliant
- HDBaseT 3.0 compliant (Backwards compatible with HDBaseT 2.0/1.0)
- Supports Deep Color input and output up to 12-bit
- Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
- 2 USB 3.0 Type-A device ports and 1 USB-C host port
- Selectable HDMI audio extraction/analog audio bypass functionality
- Supports providing PoH power from Transmitter to Receiver in same HDBaseT port
Brand:
Cypress Technology
Specifications
Product Type:
USB-C Over HDBaseT Transmitter
Encryption:
10/12bits
Transmission Range:
35m
Number of Channels:
Sound Field:
Stereo
Special Features:
HD Base T 3.0 Compliant (Backwards Compatible with HD Base T 2.0/1.0), USB 2.0 Type-A Device Ports and 1 Micro USB 2.0 Host Port
Power Rating:
18.5W
Maximum Operating Temperature:
+50°C
Chassis Color:
Black
Chassis Material:
Steel
Applications:
Household Entertainment Sharing and Control, Lecture Halls/Auditoriums and Classroom, Houses of Worship, Conference Rooms and Boardrooms, Hotel Event Spaces
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
IR, RS-232, USB 2.0
Performance
Video Format:
4K@60Hz 8bits RGB 4:4:4
Impedance Rating:
90.2kΩ
Frequency Rating:
30kHz to 50kHz
Maximum Input Sound Pressure Level:
1kHz (0dBFS)
Reference Audio Input Level:
>80dB
Inputs and Ports
Input Port Type:
1xUSB 3.0-Type C, 1xAnalog Stereo (3-Pin Terminal Block)
Output Port Type:
1xHDMI-Type A, 1xHDBaseT(RJ45)
Power
Voltage Rating:
24V
Voltage Rating:
24V
Current Rating:
2.7A
Standards
Standards Met:
US/EU Standards, CE, FCC Compliant, UL Listed
Dimensions
Width:
12.8cm
Depth:
11.2cm
Height:
2.5cm
Weight:
385g
