BLX14RE/P98H-K3E Wireless Instrument System with PGA98H Clip-On Horn Microphone, Analog, 606 to 630 MHz, Rack Mount
Please sign in so that we can notify you about a reply
Optimised for woodwind and brass performance and recording, the PGA98H is the most accessible wireless Shure gooseneck instrument microphone for elevating sound quality. BLX-R offers a simple setup and an intuitive interface in a rack-mount receiver.
Features
- BLX4, BLX4R and BLX88 Diversity Receivers: Up to 12 compatible systems per frequency band (region dependent)
- Microprocessor-controlled internal antenna diversity
- One-touch QuickScan frequency selection quickly locates the best frequency
- 1/4" and XLR audio outputs
- Two color audio status indicator LED
- Wireless Transmitters: Power and battery status LED
- Adjustable gain control
- Quick & easy frequency matching
- 2 AA batteries (included) provide up to 14 hours of continuous use
- 300 feet (91 m) operating range(line of sight)
Brand:
Shure
Specifications
Product Type:
Wireless Instrument System with PGA98H Clip-On Horn Microphone
Polar Pattern:
Cardioid
Microphone Type:
Clip-On Instrument
Mounting Type:
Rack Mount
Receiver Type:
Tabletop
Microphone Polar Pattern:
Cardioid
Antenna Type:
External
Transmission Format:
Analog
Number of Transmitter per Band:
12
Diversity Type:
Diversity
Series:
BLX
Transmitter Type:
Bodypack
Special Features:
Up to 12 Compatible Systems per Frequency Band (Region Dependent), Microprocessor-Controlled Internal Antenna Diversity, One-Touch QuickScan Frequency Selection Quickly Locates the Best Frequency, 1/4" and XLR Audio Outputs, Two Color Audio Status Indicat
Wireless Technology:
Analog UHF
Wireless Distance Range:
91m
RF Frequency Rating:
606 to 630MHz
Maximum Operating Temperature:
+50°C
Built-In Recorder (Yes/No):
No
Indicator Type:
LED
Material:
ABS
Minimum Operating Temperature:
-18°C
Includes:
Wireless Instrument System, PGA98H Clip-On Horn Microphone
Performance
Reference Audio Input Level:
0dB, -16 to +10dBV
Output Power Rating:
10mW
Power
Power Source Type:
Battery, 12 to 18V DC
Battery Type:
2xAA
Battery Life:
14hrs
Dimensions
Length:
11cm
Width:
6.4cm
Height:
2.1cm
Weight:
75g
