WPaH-AT100 Remote Wall Attenuator Panel Control, 70/100V, 100W
Please sign in so that we can notify you about a reply
The WPaH-AT100 is a 70/100 V line attenuator, with an integrated 24 VDC priority relay. Maximum output power: 100 W WPa is a series of remote control wall panels for systems and interconnecting audio signals. It marks a development of its predecessor, the WPm series, with a modern, elegant, discrete aesthetic, designed in collaboration with Italdesign Giugiaro. WPa series includes surface-mount installation box.
Brand:
Ecler
Specifications
Product Type:
Remote Wall Panel Control
Maximum Operating Temperature:
40°C
Colour:
White
Applications:
Retail, Education, Corporate, Sports & Wellness, Hospitality
Installation Type:
Surface Mount
Operating Humidity:
Minimum Operating Temperature:
-10°C
Included Accessories:
Surface Mount Box
Performance
Impedance Rating:
10Ω (Line), >1kΩ (Mic)
Signal-to-Noise Ratio:
>105dB (Line), >90dB (Mic)
Frequency Response:
5Hz to 30kHz (Line), 10Hz to 40kHz (Mic)
CMRR:
>55dB@1kHz
Output Power Rating:
100W
Input Sensitivity:
-10dBV (Line), -40dBV, -20dBV (Mic)
Power
Voltage Rating:
70/100V
Dimensions
Width:
17.2cm
Depth:
3.8cm
Height:
8.6cm
Weight:
0.6kg
Shipping Weight:
0.7kg
No reviews found
