CA120 Stereo Compact Amplifier with a Mic/Line input, 2X60WRMS@4Ω
Please sign in so that we can notify you about a reply
CA120 is a 2 x 60 WRMS @ 4 ohm stereo amplifier with a tiny size but amazing remote control features: serial RS-232 port, IR receiver and 0-10 VDC remote port. It's an ideal solution in those audiovisual applications which require integration with external control devices: education classrooms, meeting rooms, multimedia presentations, retail shops, etc.
Features
- 2 x 60 W RMS @ 4Ω amplifier
- Universal external power supply
- AUTO STANDBY function: in the absence of an audio signal the unit automatically goes into STANDBY mode, minimising power consumption
- Lightweight, silent, high-performance amplifier (fan-free convection cooling)
- Suitable for stereo and parallel (mono)
- 1 switchable balanced mic / unbalanced line input, with high quality microphone preamplifier, phantom power supply, noise gate and “talkover” function or priority over the rest of input
- 3 stereo lines (not balanced)
- 2-band independent tone control (Bass, Treble) for the microphone / line 3 and line 1&2 input connection.
- Auxiliary output for liaison with other amplifiers or external audio devices
- Local control by digital rotary knob (“encoder”)
- Remote control by infrared remote control
- Remote control by WPmVOL or WPmVOL-SR (0-10 VDC) wall panel
- RS-232 control port, compatible with EclerCOMM software (free) and control protocol CANET
- MUTE port to silence the entire unit by closing external contact
Brand:
Ecler
Specifications
Product Type:
Compact Amplifier
Number of Channels:
Input: 3, Output: 2 +1 Auxillary
Special Features:
Amazing Remote Control Features: Serial RS-232 Port, IR Receiver and 0-10 VDC Remote Port
Power Rating:
<2.5W (Standby), 24W (1/8 Rated Power), 52W (1/3 Rated Power)
Maximum Operating Temperature:
40°C
Applications:
Education Classroom, Meeting Room, Multimedia Presentation, Retail Shop
Indicator Type:
LED
Humidity:
<85%
Minimum Operating Temperature:
-10°C
Includes:
REVO-IR Remote Control
Performance
Signal-to-Noise Ratio:
>85dB (Line), >65dB (Mic Bal)
Frequency Rating:
50/60Hz
Input Impedance Rating:
>8kΩ (Line 1/2/3), >1kΩ (Mic Bal)
CMRR:
>65dB@1kHz
Crosstalk Level:
>65dB
Input Sensitivity:
-6dBV (Line1/2/3), -20 to -50dBV (Mic Bal)
Inputs and Ports
Number of Ports:
Input: 1 (Balanced Mic/Line)/2 (Unbalanced Line)
Dimensions
Width:
16cm
Depth:
21cm
Height:
4.8cm
Weight:
0.9kg
