MPX48 4 Zone Paging Microphone, Cardioid, Black, 50Hz to 16kHz
Please sign in so that we can notify you about a reply
The MPX series are paging microphones specifically designed for use in combination with MTX series audio matrix systems. The MPX48 is the 4-zone system allowing it being used in combination with an MTX48 4-zone audio matrix system. The modern shaped enclosure is finished with a real glass front panel provided with an anti-glare coating. This offers a microphone with elegant outlook which will be appreciated in any office or even design interior environment. The controls are integrated in the glass panel through capacitive touch button principle without any mechanically moving parts, same as the indicator LED’s which are completely blended. This guarantees a real high-end outlook and user experience.
An integrated chime tone is audible before each announcement. Announcements are made through the integrated pipe-neck microphone with a cardioid pickup pattern, which can be tilted to the desired angle. Both zone selection and data bus indicators are implemented, giving an overview of the systems current operation mode and data bus occupation. Quick operation is made possible using the ‘select’ & ‘clear all’ buttons, while the ‘push-to-talk’ (PTT) button must be pressed during announcements. Connection to the matrix system is done through a fixed connection cable with a length if 2 meter.
This distance can be extended to a maximum length of 300m using standard CAT5E (or better) twisted pair cabling. Cascading multiple paging stations is possible using the priority-based (user-configurable) data bus, when using the additional junction box ARJ03P.
Features
- High quality back electret condenser capsule with cardioid pickup pattern
- Level & status indication LED’s
- Tiltable pipe-neck microphone
- Surface Touch™ front panel
- Capacitive & illuminated selection buttons (4x)
Brand:
Audac
Specifications
Product Type:
4 Zone Paging Microphone
Connection Type:
RJ45
Polar Pattern:
Cardioid
Element Type:
Back Electret Condenser
Special Features:
Level and Status Indication LED’s, Capacitive & Illuminated Selection Buttons (4x)
Colour:
Black
Applications:
Corporate, Sporting Facility
Includes:
Windscreen, 2m Connection Cable (Fixed)
Performance
Sensitivity Rating:
45dB
Frequency Rating:
50Hz to 16kHz
Maximum Sound Pressure Level:
130dB
Inputs and Ports
Output Connector Type:
RJ45
Power
Voltage Rating:
24V DC
Dimensions
Length:
25cm
Width:
22.1cm
Depth:
11.1cm
Height:
4.3cm
Weight:
0.3kg
