CONGRESS2.3E/W 2 x AXIR + BASO10 + EPA254 White
Please sign in so that we can notify you about a reply
Description
CONGRESS2.3E/W – a set of a BASO10/W subwoofer with a power of 225 W RMS, two AXIR/W speaker systems and an EPA254 amplifier. EPA254 – low-impedance (8 Ohm) class D amplifier, output power 2x150 W + 500 W/Sub, AXIR/W – acoustic column with 12x2'' speakers with sensitivity 86 dB, power 120 W RMS. White color.
Features
- Ultra-thin compact sound columns
- High intelligibility at medium distances in rooms with difficult acoustics
- The set is available in two color options - black (/B) and white (/W)
Brand:
Audac
Specifications
Product Type:
Design Column Speaker, Compact Cabinet, Quad-Channel Amplifier
Coverage Angle:
170° (Horizontal)x20° (Vertical)
Number of Included Speakers:
2
Driver Size:
Speaker: 2in, Subwoofer: 10in (Ferrite)
Speaker Configuration:
Broadband Column
Series:
KYRA, BASO, EPA
Colour:
White
Applications:
Hotel, Corporate, Residential, Bar & Restaurant, Retail, Education, Club, Museum & Themepark, Sporting Facility, Event, Houses of Worship
Enclosure Type:
Bass Reflex Cabinet (Subwoofer)
Material:
Aluminium (Speaker), Plywood with Structured Coating (Subwoofer), Steel (Amplifier)
Humidity:
95%
Operating Temperature Range:
-10 to 50°C (Speaker), -20 to 60°C (Subwoofer), 0 to 40°C (Amplifier)
Included Accessories:
Wall Mounting Bracket
Performance
Amplifier Class:
Class D
Impedance Rating:
Speaker: 6Ω, Subwoofer: 8Ω, Amplifier: 12kΩ (Balanced)
SNR Ratio:
>90dB
Loudspeaker Sound Level:
113dB (Speaker), 120dB (Subwoofer)
Loudspeaker Power Rating:
Speaker: 120W (RMS/AES)/480W (Peak), Subwoofer: 225W (RMS/AES)/900W (Peak)
Loudspeaker Frequency Rating:
Speaker: 100Hz to 17kHz@±3dB/80Hz to 19kHz@-10dB, Subwoofer: 54Hz to 1.2kHz@±3dB/38Hz to 2kHz@-10dB
Amplifier Frequency Rating:
20Hz to 20kHz@±3dB
Amplifier Sensitivity:
0dB@1VRMS
Amplifier Power Rating:
4x250W@4Ω, 4x130W@8Ω, 2x500W@8Ω
Inputs and Ports
Number of I/O Connector:
Subwoofer: 2, Amplifier: 1 (Input), 1 (Output)
I/O Interface Type:
Subwoofer: Speakon Compatible Connector in Recessed Connector Dish (Linkthrough), Amplifier: 3-Pin XLR Female Connector (Input)/2-Pin Euro Terminal Block (Output)
Power
Voltage Rating:
100V
Dimensions
Width:
7cm (Speaker), 32cm (Subwoofer), 48.2cm (Amplifier)
Depth:
10.5cm (Speaker), 38cm (Subwoofer), 33cm (Amplifier)
Height:
100.5cm (Speaker), 38cm (Subwoofer), 4.4cm (Amplifier)
Weight:
4.2kg (Speaker), 10kg (Subwoofer), 4.7kg (Amplifier)
