FORTE8.6/W 4 x VEXO8 + 2 x BASO15 + SMQ750 White version
Please sign in so that we can notify you about a reply
The contemporary and compact design of both the VEXO8 loudspeakers and the BASO15 bass cabinets makes the FORTE8.6 set suitable for both fixed and mobile applications where a powerful solution with a small footprint is required. Powered by a SMQ750 WaveDynamics™ Class-D power amplifier, this system, using four VEXO8 loudspeakers and two BASO15 bass cabinets, can cover areas of around 400 m² with a stunning sound.
Features
- Compact solution
- Exceptional powerful & clear bass
- High-efficiency Class-D amplifier
- WaveDynamics™ technology
Brand:
Audac
Specifications
Product Type:
Compact High-Power Speaker, Compact Cabinet, Quad-Channel Power Amplifier
Coverage Angle:
100° (Horizontal)x80° (Vertical)
Number of Included Speakers:
4
Driver Size:
Speaker: 1in (HF)/8in (MF)/8in (LF), Subwoofer: 15in (Ferrite)
Indoor/Outdoor:
Indoor
Speaker Configuration:
Two Way
Music Level:
4
Speech Level:
2
Series:
VEXO, BASO, SMQ
Colour:
White
Applications:
Hotel, Corporate, Bar & Restaurant, Retail, Club, Event, Sporting Facility
Enclosure Type:
Bass Reflex Cabinet (Subwoofer)
Material:
Medium Density Fibreboard with Structured Coating (Speaker), Plywood with Structured Coating (Subwoofer), Steel (Amplifier)
Humidity:
95%
Operating Temperature Range:
-20 to 60°C (Speaker), -20 to 60°C (Subwoofer), 0 to 40°C (Amplifier)
Included Accessories:
Two Way Revolving Mounting Bracket
Performance
Amplifier Class:
Class D
Impedance Rating:
Speaker: 8Ω, Subwoofer: 8Ω, Amplifier: 10kΩ (Balanced)
SNR Ratio:
>95dB
Loudspeaker Sound Level:
99dB (Speaker)
Loudspeaker Power Rating:
Speaker: 175W (RMS/AES)/700W (Peak), Subwoofer: 700W (RMS/AES)/2800W (Peak)
Loudspeaker Frequency Rating:
Speaker: 65Hz to 20kHz@±3dB/55Hz to 20kHz@-10dB, Subwoofer: 38Hz to 300Hz@±3dB/34Hz to 1kHz@-10dB
Coverage Area:
400sq m
Crossover Frequency:
1.25kHz
Crossover Type:
Passive Built-In
Amplifier Frequency Rating:
20Hz to 20kHz@±3dB
Amplifier Sensitivity:
-19.5 to 27dB
Amplifier Power Rating:
4x750W@4Ω, 4x380W@8Ω, 2x1500W@8Ω
Inputs and Ports
Number of I/O Connector:
Speaker: 2, Subwoofer: 2, Amplifier: 1 (Input), 1 (Output)
I/O Interface Type:
Speaker: Speaker Connector (Linkthrough), Subwoofer: Speakon Compatible Connector in Recessed Connector Dish (Linkthrough), Amplifier: XLR & 3-Pin Euro Terminal Block (Input)/Speakon Compatible & 2-Pin Euro Terminal Block (Output)
Power
Voltage Rating:
100 to 120, 220 to 240V AC
Dimensions
Width:
25cm (Speaker), 45cm (Subwoofer), 48.2cm (Amplifier)
Depth:
26.2cm (Speaker), 52.5cm (Subwoofer), 42cm (Amplifier)
Height:
38cm (Speaker), 53.4cm (Subwoofer), 8.8cm (Amplifier)
Weight:
9.7kg (Speaker), 31kg (Subwoofer), 8.4Kg (Amplifier)
