SUBLI2.5E/B 4 x ATEO2 + BASO10 + EPA104 Black
Please sign in so that we can notify you about a reply
Don’t let size fool you. Thanks to the combination of the extremely compact ATEO2 loudspeakers and a BASO10 bass cabinet you no longer need to worry about impressing your listener. This SUBLI2.3E solution allows you to produce crystal clear sound in any environment, guaranteeing an unsurpassable sound experience with elegant aesthetics. Powered by an EPA104 Class-D amplifier, this system, using two ATEO2 loudspeakers and a BASO10 bass cabinet can cover with true-to-nature high-fidelity music and speech areas of around 30 m².
Features
- Impressive compact design
- CleverMount™ Installation
- High-efficiency Class-D amplifier
- Room-filling sound experience
Brand:
Audac
Specifications
Product Type:
Compact Wall Speaker, Compact Cabinet, Quad-Channel Amplifier
Coverage Angle:
145° (Horizontal)x170° (Vertical)
Diameter:
8cm (Speaker), 32cm (Subwoofer), 48.2cm (Amplifier)
Number of Included Speakers:
4
Driver Size:
Speaker: 2in, Subwoofer: 10in (Ferrite)
Indoor/Outdoor:
Indoor
Music Level:
3
Speech Level:
2
Series:
ATEO, BASO, EPA
Colour:
Black
Applications:
Hotel, Corporate, Residential, Bar & Restaurant, Retail, Education, Club, Museum & Themepark, Sporting Facility, Event
Enclosure Type:
Bass Reflex Cabinet (Subwoofer)
Material:
ABS (Speaker), Plywood with Structured Coating (Subwoofer), Steel (Amplifier)
Humidity:
95%
Operating Temperature Range:
-20 to 60°C (Speaker & Subwoofer), 0 to 40°C (Amplifier)
Performance
Amplifier Class:
Class D
Impedance Rating:
Speaker: 8Ω, Subwoofer: 8Ω, Amplifier: 12kΩ (Balanced)
SNR Ratio:
>90dB (Amplifier)
Loudspeaker Sound Level:
93dB (Speaker), 120dB (Subwoofer)
Loudspeaker Power Rating:
Speaker: 10W (RMS/AES)/40W (Peak), Subwoofer: 225W (RMS/AES)/900W (Peak)
Loudspeaker Frequency Rating:
Speaker: 120Hz to 20kHz@±3dB/100Hz to 20kHz@-10dB, Subwoofer: 54Hz to 1.2kHz@±3dB/38Hz to 2kHz@-10dB
Coverage Area:
50sq m
Crossover Type:
Integrated
Amplifier Frequency Rating:
20Hz to 20kHz@±3dB
Amplifier Sensitivity:
0dB@1VRMS
Amplifier Power Rating:
4x100W@4Ω, 4x50W@8Ω, 2x200W@8Ω
Inputs and Ports
Number of I/O Connector:
Speaker:1, Subwoofer:2, Amplifier: 1 (Input), 1 (Output)
I/O Interface Type:
2-Pin Euro Terminal Block (Speaker), Subwoofer: Speakon Compatible Connector in Recessed Connector Dish (Linkthrough), Amplifier: 3-Pin XLR Female Connector (Input)/2-Pin Euro Terminal Block (Output)
Power
Voltage Rating:
100 TO 240V AC
Standards
Standards Met:
Energy Star Certified
Dimensions
Depth:
11.5cm (Speaker), 38cm (Subwoofer), 33cm (Amplifier)
Height:
13.6cm (Speaker), 38cm (Subwoofer), 4.4cm (Amplifier)
Weight:
0.3kg (Speaker), 10kg (Subwoofer), 4.5kg (Amplifier)
No reviews found
