AV-CM44-VCUC-B Video Conference Camera, Black, 5xLens
Please sign in so that we can notify you about a reply
The Avonic AV-CM44-VCUC is a high-quality USB video conferencing PTZ camera with IP-control and a discrete design. The CM44-VCUC, with its versatile horizontal FOV of 83.7° and flexible 5x Zoom range, is suitable for small to medium size meeting rooms. This easy to use USB video conference camera has a plug-and-play design and can easily be controlled with the handheld IR remote. The camera has extremely silent mechanical Pan/Tilt/Zoom and can either be mounted on the wall or the ceiling. Due to the high SNR CMOS sensor in the CM44-VCUC its possible to obtain a pristine video quality even under low light conditions, making it ideal for every conference room. Easily create high-quality video that feels like you are together in the same room.
Features- Lens: High-quality wide-angle glass lens, 5x Zoom and 83.7° horizontal angle view
- Full HD 1080p30: With 1/2.8”high-quality CMOS sensor (2.07 Megapixel) the camera has a resolution of 1920 x 1080p30 and achieves a picture of great quality
- Control: Control the camera with common protocols: VISCA over IP (RJ45), Visca and Pelco-D/P (RS232/RS485) or IR remote control (included)
- Low light: High SNR CMOS combined with digital noise reduction, the picture is clear even under low illumination (0.5 lux @ F1.8) conditions
- Output: USB 2.0 up to 1080p30
- Presets: Up to 255 presets with 0.1° accuracy
Brand:
Avonic
Specifications
Product Type:
Video Conference Camera
Lens Type:
5x
Horizontal Angle of View:
83.7° (Wide), 20° (Tele)
Tilt Speed Range:
0.1 to 70°/s
Number of Preset:
255
Horizontal Rotation Range:
±170°
Minimal Illumination:
0.5Lux@(F1.8, AGC ON)
Vertical Angle of View:
53° (Wide), 11° (Tele)
Sensor Type:
1/2.8in CMOS: 2.07 MP
Vertical Rotation Range:
-30 to +90°
Special Features:
High-Quality Glass Len, High SNR CMOS Combined with Digital Noise Reduction
Power Rating:
12W
Support Protocols:
VISCA, PELCO-D, PELCO-P, VISCA OVER IP
Colour:
Black
Applications:
Education, Video Conferencing, Broadcasting, Live Events, Churches, Healthcare, Courtroom
Operating Temperature Range:
-5 to 40°C
Performance
Video System Type:
1080pixels (30 fps), 720pixels (30 fps), 576pixels (30 fps), 540pixels (30 fps), 360pixels (30 fps), 180pixels (30 fps), 768p (30 fps), 600pixels (30 fps), 480pixels (30 fps)
Video Signal-to-Noise Ratio:
>55dB
Digital Noise Reduction:
2D and 3D Digital Noise Reduction
Scanning Mode:
Progressive, Interlaced
Pan Speed Range:
0.1 to 120°/s
Preset Accuracy:
0.1
Inputs and Ports
HD Output Type:
1920x1080pixels (30fps)
USB Type:
USB2.0: 1080pixels (30 fps)
Communication Interface:
RS-232 DIN-8, RS-485 2-Pin Phoenix
Interface Type:
RJ45
Power
Input Voltage:
12V
Power Jack Type:
EIAJ-3 - Philmore 275 Screw Lock
Current Rating:
2A
Dimensions
Length:
13.2cm
Width:
15.3cm
Depth:
18cm
Shipping Weight:
1.6kg
