CH-527RXVBD UHD+ HDMI over HDBaseT Receiver with HDR
Please sign in so that we can notify you about a reply
Features
- HDMI 1.4 With 3D, 4K×2K Support, HDCP & DVI Compliant
- Supports CEC Bypass
- Simultaneous Transmission Of Uncompressed Data Over a Single 100 M/328 Ft Cat5e/6 Cable
- Uncompressed Video 1080p, 60 Hz, 36-Bit
- audio Support Up to 7.1ch & Dolby TrueHD, Dts-HD
- 5play™ Convergence: HDMI, Lan, Bidirectionlal Poe & Control (IR & RS-232)
- Installation Friendly
Brand:
Cypress Technology
Specifications
Product Type:
HDMI Over HDBaseT Extender
Special Features:
HDMI 1.4 with 3D, 4Kx2K Support, HDCP & DVI Compliant, Supports CEC Bypass, Simultaneous Transmission Of Uncompressed Data Over a Single 100m/328ft Cat5e/6 Cable, Uncompressed Video 1080pixels, 60Hz, 36bits, Audio Support Up to 7.1ch & Dolby TrueHD, Dts-H
Power Rating:
13W
Maximum Operating Temperature:
+40°C
Chassis Material:
Aluminium
Applications:
Household Entertainment Sharing and Control, Lecture Room Display and Control, Showroom Display and Control, Meeting Room Presentation and Control, Classroom Display and Control
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Storage Temperature Range:
-20 to +60°C
Performance
Maximum Input Resolution:
480i, 1080pixels@50Hz/60Hz, 1080pixels@24Hz
Inputs and Ports
Input Port Type:
1xHDMI, 1xIR Extender, 1xRS-232, 1xLAN
Output Port Type:
1xCAT5e/6/7, 1xIR Blaster
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Standards
Standards Met:
CE, FCC Compliant, UL Listed
Dimensions
Width:
10.2cm
Depth:
11.3cm
Height:
2.5cm
