CV-400H HDMI to Video Scan Converter
Please sign in so that we can notify you about a reply
This HDMI to Composite Converter will convert an HDMI digital signal to an analog NTSC or PAL signal with analog (L/R) stereo audio. This device provides the ability to convert a high definition signal to a standard definition resolution (480i or 576i) for use with DVRs or VCRs. The device is HDMI and DVI compliant and has features such as 3D noise reduction, frame rate conversion, adaptive contrast enhancement as well as a simplified on-screen display (OSD) allowing easy display of current settings.
Features
- HDMI and DVI compliant
- Converts video signal from HDMI source to NTSC or PAL signal
- Converts digital audio from HDMI source to analog stereo audio
- Accepts a wide range of HDTV input resolutions, from 480p to 720p@60 Hz and PC from VGA@60 Hz to WXGA@60 Hz
- Underscan/Overscan option
- 3D noise reduction in both temporal and spatial domain
- Arbitrary frame rate conversion
- Adaptive contrast enhancement
Brand:
Cypress Technology
Specifications
Product Type:
HDMI to Video Scan Converter
Silkscreen Color:
White
Special Features:
Underscan/Overscan Option, 3D Noise Reduction in Both Temporal and Spatial Domain, Arbitrary Frame Rate Conversion, Adaptive Contrast Enhancement
Power Rating:
3W
Maximum Operating Temperature:
+40°C
Chassis Material:
Plastic
Applications:
HDMI Signal Convert Into Composite NTSC or PAL Signal, Digital Audio Signal Convert Into Analog Audio Signal
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
HDMI to Composite Converter Box, 5V / 1A DC Power Adaptor, Operation Manual
Performance
Resolution:
480pixels, 576pixels & 720pixels, VGA@60Hz / 72 / 75 / 85, SVGA@56 / 60 / 72 / 75 / 85, XGA@60Hz / 70 / 75, WXGA(1224x768, 1280x768, 1280x800)@60HzRB / 60
Inputs and Ports
Input Port Type:
HDMI
Input Signal Type:
HDMI
Dimensions
Width:
11.4cm
Depth:
6.5cm
Height:
2.6cm
Weight:
120g
